Ultrasound for Early Detection
Cavitation is nearly unavoidable and when left unchecked it will silently erode the efficiency and reliability of fluid systems. But its occurrence can be mitigated through proper design, operation, and monitoring techniques. Therefore, it is important to actively monitor and address the conditions that lead to cavitation.
Maintaining optimal operating conditions starts with proper design and is upheld through condition monitoring. Operators can prevent costly damage, reduce maintenance costs, and extend asset life by proactively correcting conditions that lead to pump cavitation.
What is Cavitation? Why should we care?
Cavitation occurs within a pump when the pressure of a liquid rises and falls causing bubbles to form and implode. The ensuing shockwaves – after hours of operation and billions of implosions – impart severe wear on impellers and fluid systems. (Figure 2).
In addition to shortened lifespan of the impeller, operators must also consider the broader impacts of cavitation.
Excessive machinery vibration affects the foundation, damages mechanical seals, and shortens bearing life. The sheering of metal components can also contaminate production processes.
Figure 1: Asphalt Pump Damaged by (Image at top of page)
Figure 2: Impeller Pitted from Cavitation
Cavitation Conditions
Inadequate Net Positive Suction Head (NPSH)
NPSH represents the difference between the pressure at the pump inlet and the vapor pressure of the fluid. When there isn’t enough pressure at the inlet, cavitation is likely to occur.
High Fluid Temperature
Fluctuations in fluid temperature also results in vapour pressure changes. In operations with high temperatures, improper cooling of components can heat fluid unexpectedly and unnecessarily.
High Flow Rates not in Accordance with System Specs
Operating equipment outside of its factory specifications inevitably leads to problems. This is especially true for pumps, where proper system design and pump selection are essential. If a pump is oversized for an application or if the flow rate operates below or above the pump’s design range, it creates conditions that lead to cavitation.
Low Pressure Zones in the Pump
Certain pump designs and configurations create low-pressure areas within the pump which can trigger cavitation under specific operating conditions.
Low Suction Pressure and Blockages
Insufficient pressure on the pump’s suction side will drop the vapor pressure of a liquid. Any form of restriction, such as clogged filters, malfunctioning valves, or partially closed piping, as well as poorly designed or installed suction lines will result in insufficient pressure.
Monitoring Cavitation
The traditional approach to identifying pump cavitation utilized vibration analysis, and it was effectively the best solution we had at the time, but it had limitations:
By the time cavitation causes significant vibrational changes to a pumping system and the surrounding assets, it has already reached an advanced stage. By this time, damage has occurred to components like the impeller, seals, and bearings.
Pumps also operate in complex environments with multiple vibration sources, such as motors, misalignment, bearing wear, and external machinery. This poses challenges for isolating vibration signals only related to cavitation.
Additionally, vibration analysis is a specialist’s technology that requires skilled technicians to distinguish cavitation from other issues. The process can be time-consuming and depends on properly positioned and calibrated sensors for accurate results. There are quicker methods that require less experience and can be performed with minimal training.
The early, subtle signs of cavitation first occur in higher frequencies before any damage has been imparted on the impeller. But if technicians attempt to detect these signals using low frequency vibration, they can be masked by the overall vibration inherent in the asset. Ultrasound monitoring addresses this limitation by capturing the high-frequency sounds produced by imploding bubbles. Therefore, allowing for timely maintenance planning and interventions.
Inspection Method
Ultrasound inspection for pump cavitation is straightforward. By placing a contact ultrasound sensor on the pump’s volute and listening for the distinct sound of bubbles imploding, technicians are able to quickly and easily identify cavitation.
In Figure 4, a 10-second time waveform shows telltale signs of cavitation. Observing the time waveform while listening to the audio signal reveals hundreds of micro sonic impacts which could only be caused by the collapsing of bubbles.
Figure 3: Magnetic Ultrasound Sensor Placement
Figure 4: 10-Second Ultrasound Time Waveform Recorded on a Volute showing signs of Cavitation
Ultrasound data collectors with a high sampling rate provide more data samples per second. This better captures the implosions and leads to a more confident assessment.
Two opinions are always better than one. Once cavitation has been detected and eliminated with ultrasound, vibration analysis can now be deployed to detect the presence of imbalance and misalignment. These failure modes are detrimental but also mimic and contribute to the symptoms of cavitation. Integrating insights from multiple diagnostic tools will better serve condition monitoring teams while identifying the root cause of cavitation and other failure modes.
Preventing Cavitation
If pump cavitation is destroying your fluid systems, increase the NPSH. Sufficient pressure upstream of the pump’s impeller ensures the suction side stays above the liquid’s vapor pressure.
Increasing the NPSH can be achieved by:
Increasing the Upstream Reservoir’s Water Level
Raising the water level in the upstream reservoir increases the pressure on the suction side of the pump. This added weight helps prevent the formation of bubbles by maintaining the liquid’s pressure above its vapor pressure, which is critical for avoiding cavitation bubbles.
Minimize Anything That Can Restrict Flow
Flow restrictions can be caused by sharp bends, clogged filters, failed valves, and undersized pipes. They create pressure drops that reduce the available NPSH (NPSHa). By using properly sized and configured piping, regularly maintaining filters, testing valve condition, and eliminating unnecessary restrictions, liquids will flow smoother into the pump, and the risk of cavitation is reduced.
Operate the Pump at Lower Flow Rates
Installing an inducer or operating the pump at lower flow rates can help maintain sufficient suction pressure to prevent cavitation. An inducer is a specialized axial-flow impeller. It increases the pressure at the pump’s inlet. Similarly, operating the pump at lower flow rates helps stabilize and regulate the suction side pressure.
Review System Specifications and Confirm Design Requirements
A system mis-engineered for the application is doomed from the start. Ensuring the fluid system is properly matched to the application is crucial for avoiding cavitation and overall faulty operation. The first step in this process involves selecting the correct pump for the application and verifying that the NPSH required (NPSHr) matches or is less than the NPSHa.
Early Detection of Ultrasound Condition Monitoring
The earliest indication of a change in an asset’s condition is discovered in the ultrasonic domain, no matter how subtle those changes might be. Ultrasound senses the high frequency changes in an asset’s function, allowing inspectors to anticipate failures and plan maintenance interventions with a larger window of opportunity.
Hyper-sensitivity towards friction, impacting, and turbulence not only gives ultrasound condition monitoring leading detection capabilities – but also allows for extreme versatility in detecting a wide range of defects across a number of different asset classes.
